PBC093 - TTW

  • 9,000 BTU/h nominal capacity
  • 9.7 CEER
  • Voltage 230/208V
Amana Through The Wall (TTW)

* Complete warranty details available from your local dealer or at www.amana-ptac.com. We will repair or replace, free of charge (to include labor), any part of a unit that proves to be defective due to workmanship or materials within the first year after the date of purchase.


  • U.L (Underwriters Laboratory) listed; USA and Canada
  • Slide-out chassis type for easy installation and service accessibility
  • 2 fan speeds: High & Low
  • High speed fan only option
  • Top air discharge with 4-way adjustable air throw
  • External condensation drain spout on the PBWS01A optional wall sleeve drain spout
  • Electronic touch pad with remote control
  • High energy efficiency with models up to 9.7 CEER
  • Easily removable condenser top that allows for quick and complete cleaning of outdoor coils. This access for cleaning the outdoor coil enables easy removal of dirt and debris to help lengthen the life of the compressor and other system sealed components. Remove six easy access screws and let the cleaning begin.
  • Easy access slide out filter has a permanent polypropylene filter mesh that is easy to remove and clean.
  • Easy to set switches to configure check filter light, temperature limiting capability, and fan auto cycle for heating or cooling.
  • 100% Full factory run test on all units for high reliability and dependability. Units start the first time — every time.
  • Quiet operation. Designed with guest comfort in mind — providing reliable, quiet operation for years to come.

Specifications & Literature+

Voltage 230/208
Capacity (BTU/h) 9,300/9,100
Amps 4.3/4.7
Watts 950/930
CEER 9.7
