AE09 - WRAC

Air Conditioner

  • 9,000 BTU/h nominal capacity
  • 11.0 EER
  • Voltage 230/208V
Amana WRAC Air Conditioner and Heat Pump
Amana PTAC 5 Year Parts Limited Warranty
* Complete warranty details available from your local dealer or at www.amana-ptac.com.

Features+

  • 4.0' LCDI power cord; Perpendicular plug; 20-amp circuit breaker.
  • U.L (Under Writers Laboratory) listed; USA and Canada.
  • Slide-out chasis type for easy installation and service accessibility.
  • 3 fan speeds, High, Medium and Low.
  • Fan ONLY - High, Medium and Low speed.
  • Condensate drain spout on the wall sleeve.
  • Window Kit Included.
  • Electronic touch pad with remote control
  • High energy efficiency with models up to 11.0 EER
  • Solid bottoms on outer-cases
  • 100% full factory run test on all units
  • Ball bearing fan motors
  • Multi-directional air-flow to allow for cooling or heating to any part of the room
  • Easy access slide-out filter (left or right side pullout)
  • Hydrophilic coating on evaporator and condenser Coils
  • Condensate drain spouts.
  • LCDI power cords.

Specifications & Literature+

Voltage 230/208
Capacity (BTU/h) 9,000/8,700
Amps 3.7/4.0
Watts 820/790
EER 11.0/11.0

Literature(PDF)
